WiNRADiO software options enhance the WiNRADiO receivers by introducing additional features and functions.
| Option |
Description |
|
WiNRADiO Universal Recordings Player |
The WiNRADiO Universal Recordings Player is a tool for off-line analysis, editing and conversion of files recorded by WiNRADiO applications. It is particularly useful to extract targets from big-recorded files. The application supports proprietary WiNRADiO formats RXW and WWV, standard Windows wave WAV format, and DDC format (DDC streamed in the WAV file format).
|
|
WiNRADiO Marine Application Suite - G305 |
The WiNRADiO Marine Application Suite for the WR-G305 receiver is a high-performance system specially developed for marine applications. A number of decoding facilities are included: HF Fax, NAVTEX, HF/VHF DSC and TELEX, as well as classical AM, SSB, CW and FM radio modes with coverage from 9 kHz to 1800 MHz. Automatic scheduling, recording, playback, printing and many other tools are provided. A GPS option is also available which integrates to provide a high-resolution global mapping facility.
For marine operators, this provides an excellent replacement for the discontinued WR-G33EM receiver.
|
|
|
WiNRADiO Marine Application Suite - G315 |
The WiNRADiO Marine Application Suite for the WR-G315 receiver is a high-performance system specially developed for marine applications. A number of decoding facilities are included: HF Fax, NAVTEX, HF/VHF DSC and TELEX, as well as classical AM, SSB, CW and FM radio modes with coverage from 9 kHz to 1800 MHz. Automatic scheduling, recording, playback, printing and many other tools are provided. A GPS option is also available which integrates to provide a high-resolution global mapping facility. This version also supports multiple receiver instances to suit advanced professional applications.
|
|
WiNRADiO Digital Radio Decoder |
The WiNRADiO Digital Radio Decoder provides a set of plugin applications capable of
decoding multiple types of digital radio standards including DMR/MOTOTRBO, dPMR, NXDN, D-STAR and APCO P25 (phase 1 and phase 2) standards.
The plugins use an external hardware AMBE+ 2
vocoder for voice decoding and the decoders support both single and multichannel external codec devices.
Many other useful functions for analyzing, logging, recording and filtering of received radio packets are included.
Note: An APCO trunking option is under development.
|
|
WiNRADiO Advanced Digital Suite |
The WiNRADiO Advanced Digital Suite is a collection of digital signal processing modules, fully integrated with WiNRADiO receiver software. The WiNRADiO Advanced Digital Suite offers a higher level of functionality and performance than the Standard Digital Suite and is suitable for professional and semi-professional applications.
Suitable for use with the WiNRADiO G3 receiver series, such as the G305, G313, G315, G31DDC, G33DDC, G35DDC, G65DDC, G69DDC etc. |
|
WiNRADiO Advanced Trunking Option |
The WiNRADiO Advanced Trunking Option contains full support for Motorola SmartNet, MPT1327 and EDACS trunking systems. In conjunction with the optional APCO P25 decoder, the program will follow and decode APCO P25 digitally-coded voice traffic on 3600 baud control channels (also known as Motorola Astro as well as APCO P25 native 9600 baud control channels.
Suitable for WiNRADiO WR-G305e, WR-G305i, WR-G315e, WR-G315i, WR-G39DDCi and WR-G39DDCe receivers.
Note: Cannot be used with DRD-172 or WA-0872.
|
|
WiNRADiO DRM Demodulator/Decoder |
This DRM Demodulator/Decoder Plug-in makes it possible to receive and listen to DRM transmissions on a WiNRADiO G3 Series receivers. DRM is a digital broadcasting system for short-wave, medium-wave and long-wave bands which offers a dramatic improvement over conventional analogue AM transmissions with its near-FM quality of sound.
|
|
WiNRADiO APCO P25 Decoder |
This APCO P25 Decoder Plug-in makes it possible to receive and listen to digital APCO P25 channels (phase 1 only) on WiNRADiO G305, G315 and G39DDC Series receivers. APCO Project 25 (P25) was developed by joint efforts of the Association of Public Safety Communications Officials International (APCO), the National Association of State Telecommunications Directors (NASTD), several US Federal Agencies and the National Communications System (NCS). It was established to address the need for common digital public safety radio communications standards for public safety, homeland security and emergency response. |
|
WiNRADiO WaveBase 3 |
The WiNRADiO WaveBase 3 is a combination of three functions in one: shortwave frequency database, task scheduler and audio recorder, all neatly integrated and suitable for any general-purpose G3, G3xDDC or G6xDDC series receiver.
WaveBase 3 makes it possible to easily import station frequency data and broadcast schedules from the Internet (HFCC and EiBi websites) to maintain accurate, easily searchable records that can be used to automatically control recording. Selected database records can be also easily exported as CSV-formatted files. |
|
WiNRADiO Universal FSK Decoder |
The WiNRADiO Universal FSK Decoder is an extremely versatile signal decoding utility suitable for use with the WiNRADiO G3 receiver series, such as the G305, G313, G315, G31DDC, G33DDC, G35DDC, G65DDC, G69DDC etc.
The Decoder contains several powerful analysis tools, making it possible to determine transmission characteristics of an unknown signal automatically.
The Decoder comes with the following basic protocols pre-installed: ARQ1000D, ARQ-E, ARQ-N, ARQ-6, ARQ6-70, ARQ6-90, ARQ6-98, ARQ-E3, Baudot, IRA (ASCII), Packet Radio, POL-ARQ, SITOR-A, SITOR-B, NAVTEX, Raw Bits, SI-ARQ and SWED-ARQ. Many other protocols can be added by modifying the numerous decoding and demodulation parameters the Universal FSK Decoder offers.
|
|
WiNRADiO Client/Server Option |
The WiNRADiO Client/Server Option makes it possible to remotely control a WiNRADiO receiver across all types of computer networks supporting the TCP/IP protocol. With the Client/Server Option installed, a WiNRADiO receiver can be controlled and listened to remotely, from anywhere in the world where a TCP/IP connection exists between the Client and the Server. Four versions are available:
 Client/Server Option for 1000/1500 series receivers
Client/Server Option for 3000 series receivers
Client/Server Option for 8000 series multichannel systems
Client/Server Option for G313 and G315 series receivers
Client/Server Option for G33DDC series receivers
Client/Server Option for G35DDC series receivers
Client/Server Option for G39DDC series receivers
Client/Server Option for G65DDC series receivers
Client/Server Option for G69DDC series receivers
|
|
WiNRADiO Digital Bridge™ Virtual Sound Card |
The WiNRADiO Digital Bridge™ Virtual Sound Card is a software option for WiNRADiO G3, G3xDDC, or G6xDDC series receiver which creates a Windows multimedia driver making it possible to transfer digitized audio signal streams from one application to another. It does so by creating a pair of Wave In/Out Windows devices. The WiNRADiO receiver application can send an audio stream to the Out device, and any other application can then access this stream from the In device.
This allows third-party applications that normally rely on a standard sound card for signal input, to obtain digital signal samples directly from a WiNRADiO G3, G3xDDC, or G6xDDC series receiver demodulator.
|
|
WiNRADiO Field Strength Logger Option |
The WiNRADiO Field Strength Logger Option adds a calibrated signal strength and field strength meter and logger to the WiNRADiO G313 and G315 series plus other receivers such as the G31DDC, G33DDC, G35DDC, G39DDC, G65DDC and G69DDC. It is useful wherever it is necessary to measure absolute signal or field strength levels, and store them to a file in user-definable time intervals.
For use in geographical signal coverage surveys, the Field Strength Logger employs a GPS receiver to display and store geographical co-ordinates of the measured signal. This GPS unit is supplied as part of the package. |
|
WiNRADiO Digital Suite for 1000/1500/3000 Receiver Series |
The WiNRADiO Digital Suite is a collection of digital signal processing modules, fully integrated with WiNRADiO receiver software. The WiNRADiO Digital Suite expands the power of your WiNRADiO receiver with numerous digital processing facilities, including weather fax, ACARS, packet radio, audio oscilloscope and spectrum analyzer, squelch-controlled recording, and many others.
Suitable for the 1000, 1500 and 3000 series of WiNRADiO receivers. |
|
WiNRADiO Trunking Option for 1000/1500/3000 Series |
Join the trunked radio revolution with your WiNRADiO receiver! The WiNRADiO Trunking Option includes major trunking modes; Motorola SmartNet and MPT 1327, which are the most commonly used trunking modes worldwide.
Suitable for the 1000, 1500, 3000 series of WiNRADiO receivers.
SmartNet is a registered trademark of Motorola Inc. |
|
